Tipping Ntawv Kev kub ceev Laser Perforation Tshuab
Siab ceev|40-80 hli
Substrate: 20-80gsm
Description
TDLB-D/8P Series Tipping Ntawv Laser Perforation Tshuab
Siab ceev |40-80 hli
Tsis muaj
|
Substrate |
20-80gsm |
|
Laser generator zog |
100-650W |
|
Kev ruaj ntseg |
<±2% |
|
Ntau zaus |
0-130Hz |
|
No. ntawm perforation kab |
2-8 |
|
Permeability instability |
< 6% |
|
Permeability ntau yam |
100-2000cu |
|
Max perforation ceev |
4 pcs / hli |
|
Max ntawv ceev |
600m / min |
|
Bobbin dav |
40-80 hli |
|
Max bobbin dia |
Φ520 hli |
Paub meej
-Components: laser generator, optical system, tswj system, ntawv pub zaub mov, chav dej-txias, auxiliary functions (on-line xyuas, xoom-meter mechanism, LPC, extractor kiv cua, thiab lwm yam)
-Paper feeding system tswj los ntawm German BECKHOFF servo system nrog BECKHOFF servo lub cev muaj zog.
-Tsis siv neeg suav ntawm yob txoj kab uas hla, kom ntseeg tau qhov ceev ceev ceev thiab du bobbin nto.
-Full-automatic nro tswj qhov system
-Online huab cua permeability saib,
-Txoj kev qhia lub vev xaib (LPC system) los ntawm BST.
FAQ
